King’s Snow Melt Systems are great solutions to stay ahead of the snow and ice when winter arrives. On-demand snow melt improved the safety of driveways, sidewalks, stairs and other outdoor foot-traffic areas, keeping them free from the dangers of ice. Keep your home or business safe and accessible all year long. SCM Series Mats offer the easiest solution to snow and ice build-up, providing pre-fabricated mats at 50W/SqFt (3″ spacing) that can be rolled out prior to the concrete slab being poured. Whether you are heating concerete, asphalt or pavers the SCM will keep your area clear and safe to walk on.
- For Use In Concrete, Asphalt and Under Pavers
- For Use in Sidewalks, Driveways, Stairs, Ramps, Etc.
- Pre-Fabricated Mats At 50W/SqFt (3" spacing)
- 20 Foot Cold Lead
- Twin Conductor
- Flouropolymer Insulation and Rugged PVC Jacked
- Emits Zero EMF (electromagnetic fields)
- Single Point Connection
- ETL and CSA certified for USA and Canada
- Imported to King Specifications
- 10-year limited warranty
Experience A Worry-Free Winter
On-demand snow melt improved the safety of driveways, sidewalks, stairs and other outdoor foot-traffic areas, keeping them free from the dangers of ice.
Now That’s Smart!
Relax By The Fire And Never Shovel Your Driveway Again
SCM Series Mats offer the easiest solution to snow and ice build-up, providing pre-fabricated mats at 50W/SqFt (3″ spacing) that can be rolled out prior to the concrete slab being poured.
Available Models
Ordering Information
| MODEL (24" WIDE) | UPC (093319) | VOLTS | MAT LENGTH | HEATED AREA (3" SPACING) | WATTS (48 W/FT2) | AMPS |
|---|---|---|---|---|---|---|
| SCM204824-4 | 42032 | 208 | 4.4 FT. | 8.8 SQ. FT. | 420 | 2 |
| SCM204824-6 | 42033 | 208 | 6.3 FT. | 12.5 SQ. FT. | 600 | 2.9 |
| SCM204824-8 | 42034 | 208 | 8.8 FT. | 17.5 SQ. FT. | 840 | 4 |
| SCM204824-10 | 42035 | 208 | 10.6 FT. | 21.3 SQ. FT. | 1020 | 4.9 |
| SCM204824-13 | 42036 | 208 | 13.1 FT. | 26.3 SQ. FT. | 1260 | 6.1 |
| SCM204824-15 | 42037 | 208 | 15.6 FT. | 31.3 SQ. FT. | 1500 | 7.2 |
| SCM204824-18 | 42038 | 208 | 18.1 FT. | 36.3 SQ. FT. | 1740 | 8.4 |
| SCM204824-20 | 42039 | 208 | 20.0 FT. | 40.0 SQ. FT. | 1920 | 9.2 |
| SCM204824-22 | 42040 | 208 | 22.5 FT. | 45.0 SQ. FT. | 2160 | 10.4 |
| SCM204824-26 | 42041 | 208 | 26.3 FT. | 52.5 SQ. FT. | 2520 | 12.1 |
| SCM204824-30 | 42042 | 208 | 30.6 FT. | 61.3 SQ. FT. | 2940 | 14.1 |
| SCM204824-35 | 42043 | 208 | 35.0 FT. | 70.0 SQ. FT. | 3360 | 16.2 |
| SCM204824-40 | 42044 | 208 | 40.0 FT. | 80.0 SQ. FT. | 3840 | 18.5 |
| SCM204824-44 | 42045 | 208 | 44.4 FT. | 88.8 SQ. FT. | 4260 | 20.5 |
| SCM204824-51 | 42046 | 208 | 51.3 FT. | 102.5 SQ. FT. | 4920 | 23.7 |
| SCM204824-57 | 42047 | 208 | 57.5 FT. | 115.0 SQ. FT. | 5520 | 26.5 |
Ordering Information
| MODEL (24" WIDE) | UPC (093319) | VOLTS | MAT LENGTH | HEATED AREA (4" SPACING) | WATTS (36 W/FT2) | AMPS |
|---|---|---|---|---|---|---|
| SCM203624-5 | 42048 | 208 | 5.8 FT. | 11.7 SQ. FT. | 420 | 2 |
| SCM203624-8 | 42049 | 208 | 8.3 FT. | 16.7 SQ. FT. | 600 | 2.9 |
| SCM203624-11 | 42050 | 208 | 11.7 FT. | 23.3 SQ. FT. | 840 | 4 |
| SCM203624-14 | 42051 | 208 | 14.2 FT. | 28.3 SQ. FT. | 1020 | 4.9 |
| SCM203624-17 | 42052 | 208 | 17.5 FT. | 35.0 SQ. FT. | 1260 | 6.1 |
| SCM203624-20 | 42053 | 208 | 20.8 FT. | 41.7 SQ. FT. | 1500 | 7.2 |
| SCM203624-24 | 42054 | 208 | 24.2 FT. | 48.3 SQ. FT. | 1740 | 8.4 |
| SCM203624-26 | 42055 | 208 | 26.7 FT. | 53.3 SQ. FT. | 1920 | 9.2 |
| SCM203624-30 | 42056 | 208 | 30.0 FT. | 60.0 SQ. FT. | 2160 | 10.4 |
| SCM203624-35 | 42057 | 208 | 35.0 FT. | 70.0 SQ. FT. | 2520 | 12.1 |
| SCM203624-40 | 42058 | 208 | 40.8 FT. | 81.7 SQ. FT. | 2940 | 14.1 |
| SCM203624-46 | 42059 | 208 | 46.7 FT. | 93.3 SQ. FT. | 3360 | 16.2 |
| SCM203624-53 | 42060 | 208 | 53.3 FT. | 106.7 SQ. FT. | 3840 | 18.5 |
| SCM203624-59 | 42061 | 208 | 59.2 FT. | 118.3 SQ. FT. | 4260 | 20.5 |
| SCM203624-68 | 42062 | 208 | 68.3 FT. | 136.7 SQ. FT. | 4920 | 23.7 |
| SCM203624-76 | 42063 | 208 | 76.7 FT. | 153.3 SQ. FT. | 5520 | 26.5 |
Ordering Information
| MODEL (30" WIDE) | UPC (093319) | VOLTS | MAT LENGTH | HEATED AREA (3" SPACING) | WATTS (48 W/FT2) | AMPS |
|---|---|---|---|---|---|---|
| SCM204830-3 | 42064 | 208 | 3.5 FT. | 8.8 SQ. FT. | 420 | 2 |
| SCM204830-5 | 42065 | 208 | 5.0 FT. | 12.5 SQ. FT. | 600 | 2.9 |
| SCM204830-7 | 42066 | 208 | 7.0 FT. | 17.5 SQ. FT. | 840 | 4 |
| SCM204830-8 | 42067 | 208 | 8.5 FT. | 21.3 SQ. FT. | 1020 | 4.9 |
| SCM204830-10 | 42068 | 208 | 10.5 FT. | 26.3 SQ. FT. | 1260 | 6.1 |
| SCM204830-12 | 42069 | 208 | 12.5 FT. | 31.3 SQ. FT. | 1500 | 7.2 |
| SCM204830-14 | 42070 | 208 | 14.5 FT. | 36.3 SQ. FT. | 1740 | 8.4 |
| SCM204830-16 | 42071 | 208 | 16.0 FT. | 40.0 SQ. FT. | 1920 | 9.2 |
| SCM204830-18 | 42072 | 208 | 18.0 FT. | 45.0 SQ. FT. | 2160 | 10.4 |
| SCM204830-21 | 42073 | 208 | 21.0 FT. | 52.5 SQ. FT. | 2520 | 12.1 |
| SCM204830-24 | 42074 | 208 | 24.5 FT. | 61.3 SQ. FT. | 2940 | 14.1 |
| SCM204830-28 | 42075 | 208 | 28.0 FT. | 70.0 SQ. FT. | 3360 | 16.2 |
| SCM204830-32 | 42076 | 208 | 32.0 FT. | 80.0 SQ. FT. | 3840 | 18.5 |
| SCM204830-35 | 42077 | 208 | 35.5 FT. | 88.8 SQ. FT. | 4260 | 20.5 |
| SCM204830-41 | 42078 | 208 | 41.0 FT. | 102.5 SQ. FT. | 4920 | 23.7 |
| SCM204830-46 | 42079 | 208 | 46.0 FT. | 115.0 SQ. FT. | 5520 | 26.5 |
Ordering Information
| MODEL (30" WIDE) | UPC (093319) | VOLTS | MAT LENGTH | HEATED AREA (4" SPACING) | WATTS (36 W/FT2) | AMPS |
|---|---|---|---|---|---|---|
| SCM203630-4 | 42080 | 208 | 4.7 FT. | 11.7 SQ. FT. | 420 | 2 |
| SCM203630-6 | 42081 | 208 | 6.7 FT. | 16.7 SQ. FT. | 600 | 2.9 |
| SCM203630-9 | 42082 | 208 | 9.3 FT. | 23.3 SQ. FT. | 840 | 4 |
| SCM203630-11 | 42083 | 208 | 11.3 FT. | 28.3 SQ. FT. | 1020 | 4.9 |
| SCM203630-14 | 42084 | 208 | 14.0 FT. | 35.0 SQ. FT. | 1260 | 6.1 |
| SCM203630-16 | 42085 | 208 | 16.7 FT. | 41.7 SQ. FT. | 1500 | 7.2 |
| SCM203630-19 | 42086 | 208 | 19.3 FT. | 48.3 SQ. FT. | 1740 | 8.4 |
| SCM203630-21 | 42087 | 208 | 21.3 FT. | 53.3 SQ. FT. | 1920 | 9.2 |
| SCM203630-24 | 42088 | 208 | 24.0 FT. | 60.0 SQ. FT. | 2160 | 10.4 |
| SCM203630-28 | 42089 | 208 | 28.0 FT. | 70.0 SQ. FT. | 2520 | 12.1 |
| SCM203630-32 | 42090 | 208 | 32.7 FT. | 81.7 SQ. FT. | 2940 | 14.1 |
| SCM203630-37 | 42091 | 208 | 37.3 FT. | 93.3 SQ. FT. | 3360 | 16.2 |
| SCM203630-42 | 42092 | 208 | 42.7 FT. | 106.7 SQ. FT. | 3840 | 18.5 |
| SCM203630-47 | 42093 | 208 | 47.3 FT. | 118.3 SQ. FT. | 4260 | 20.5 |
| SCM203630-54 | 42094 | 208 | 54.7 FT. | 136.7 SQ. FT. | 4920 | 23.7 |
| SCM203630-61 | 42095 | 208 | 61.3 FT. | 153.3 SQ. FT. | 5520 | 26.5 |
Ordering Information
| MODEL (36" WIDE) | UPC (093319) | VOLTS | MAT LENGTH | HEATED AREA (3" SPACING) | WATTS (48 W/FT2) | AMPS |
|---|---|---|---|---|---|---|
| SCM204836-2 | 42096 | 208 | 2.9 FT. | 8.8 SQ. FT. | 420 | 2 |
| SCM204836-4 | 42097 | 208 | 4.2 FT. | 12.5 SQ. FT. | 600 | 2.9 |
| SCM204836-5 | 42098 | 208 | 5.8 FT. | 17.5 SQ. FT. | 840 | 4 |
| SCM204836-7 | 42099 | 208 | 7.1 FT. | 21.3 SQ. FT. | 1020 | 4.9 |
| SCM204836-8 | 42100 | 208 | 8.8 FT. | 26.3 SQ. FT. | 1260 | 6.1 |
| SCM204836-10 | 42101 | 208 | 10.4 FT. | 31.3 SQ. FT. | 1500 | 7.2 |
| SCM204836-12 | 42102 | 208 | 12.1 FT. | 36.3 SQ. FT. | 1740 | 8.4 |
| SCM204836-13 | 42103 | 208 | 13.3 FT. | 40.0 SQ. FT. | 1920 | 9.2 |
| SCM204836-15 | 42104 | 208 | 15.0 FT. | 45.0 SQ. FT. | 2160 | 10.4 |
| SCM204836-17 | 42105 | 208 | 17.5 FT. | 52.5 SQ. FT. | 2520 | 12.1 |
| SCM204836-20 | 42106 | 208 | 20.4 FT. | 61.3 SQ. FT. | 2940 | 14.1 |
| SCM204836-23 | 42107 | 208 | 23.3 FT. | 70.0 SQ. FT. | 3360 | 16.2 |
| SCM204836-26 | 42108 | 208 | 26.7 FT. | 80.0 SQ. FT. | 3840 | 18.5 |
| SCM204836-29 | 42109 | 208 | 29.6 FT. | 88.8 SQ. FT. | 4260 | 20.5 |
| SCM204836-34 | 42110 | 208 | 34.2 FT. | 102.5 SQ. FT. | 4920 | 23.7 |
| SCM204836-38 | 42111 | 208 | 38.3 FT. | 115.0 SQ. FT. | 5520 | 26.5 |
Ordering Information
| MODEL (36" WIDE) | UPC (093319) | VOLTS | MAT LENGTH | HEATED AREA (4" SPACING) | WATTS (36 W/FT2) | AMPS |
|---|---|---|---|---|---|---|
| SCM203636-3 | 42112 | 208 | 3.9 FT. | 11.7 SQ. FT. | 420 | 2 |
| SCM203636-5 | 42113 | 208 | 5.6 FT. | 16.7 SQ. FT. | 600 | 2.9 |
| SCM203636-7 | 42114 | 208 | 7.8 FT. | 23.3 SQ. FT. | 840 | 4 |
| SCM203636-9 | 42115 | 208 | 9.4 FT. | 28.3 SQ. FT. | 1020 | 4.9 |
| SCM203636-11 | 42116 | 208 | 11.7 FT. | 35.0 SQ. FT. | 1260 | 6.1 |
| SCM203636-13 | 42117 | 208 | 13.9 FT. | 41.7 SQ. FT. | 1500 | 7.2 |
| SCM203636-16 | 42118 | 208 | 16.1 FT. | 48.3 SQ. FT. | 1740 | 8.4 |
| SCM203636-17 | 42119 | 208 | 17.8 FT. | 53.3 SQ. FT. | 1920 | 9.2 |
| SCM203636-20 | 42120 | 208 | 20.0 FT. | 60.0 SQ. FT. | 2160 | 10.4 |
| SCM203636-23 | 42121 | 208 | 23.3 FT. | 70.0 SQ. FT. | 2520 | 12.1 |
| SCM203636-27 | 42122 | 208 | 27.2 FT. | 81.7 SQ. FT. | 2940 | 14.1 |
| SCM203636-31 | 42123 | 208 | 31.1 FT. | 93.3 SQ. FT. | 3360 | 16.2 |
| SCM203636-35 | 42124 | 208 | 35.6 FT. | 106.7 SQ. FT. | 3840 | 18.5 |
| SCM203636-39 | 42125 | 208 | 39.4 FT. | 118.3 SQ. FT. | 4260 | 20.5 |
| SCM203636-45 | 42126 | 208 | 45.6 FT. | 136.7 SQ. FT. | 4920 | 23.7 |
Ordering Information
| MODEL (24" WIDE) | UPC (093319) | VOLTS | MAT LENGTH | HEATED AREA (3" SPACING) | WATTS (48 W/FT2) | AMPS |
|---|---|---|---|---|---|---|
| SCM244824-5 | 42128 | 240 | 5.0 FT. | 10.0 SQ. FT. | 480 | 2 |
| SCM244824-7 | 42129 | 240 | 7.5 FT. | 15.0 SQ. FT. | 720 | 3 |
| SCM244824-10 | 42130 | 240 | 10.0 FT. | 20.0 SQ. FT. | 960 | 4 |
| SCM244824-12 | 42131 | 240 | 12.5 FT. | 25.0 SQ. FT. | 1200 | 5 |
| SCM244824-15 | 42132 | 240 | 15.0 FT. | 30.0 SQ. FT. | 1440 | 6 |
| SCM244824-18 | 42133 | 240 | 18.1 FT. | 36.3 SQ. FT. | 1740 | 7.3 |
| SCM244824-20 | 42134 | 240 | 20.6 FT. | 41.3 SQ. FT. | 1980 | 8.3 |
| SCM244824-23 | 42135 | 240 | 23.1 FT. | 46.3 SQ. FT. | 2220 | 9.3 |
| SCM244824-25 | 42136 | 240 | 25.6 FT. | 51.3 SQ. FT. | 2460 | 10.3 |
| SCM244824-30 | 42137 | 240 | 30.6 FT. | 61.3 SQ. FT. | 2940 | 12.3 |
| SCM244824-35 | 42138 | 240 | 35.6 FT. | 71.3 SQ. FT. | 3420 | 14.3 |
| SCM244824-40 | 42139 | 240 | 40.6 FT. | 81.3 SQ. FT. | 3900 | 16.3 |
| SCM244824-46 | 42140 | 240 | 46.3 FT. | 92.5 SQ. FT. | 4440 | 18.5 |
| SCM244824-51 | 42141 | 240 | 51.3 FT. | 102.5 SQ. FT. | 4920 | 20.5 |
| SCM244824-59 | 42142 | 240 | 59.4 FT. | 118.8 SQ. FT. | 5700 | 23.8 |
| SCM244824-66 | 42143 | 240 | 66.9 FT. | 133.8 SQ. FT. | 6420 | 26.8 |
Ordering Information
| MODEL (24" WIDE) | UPC (093319) | VOLTS | MAT LENGTH | HEATED AREA (4" SPACING) | WATTS (36 W/FT2) | AMPS |
|---|---|---|---|---|---|---|
| SCM243624-6 | 42144 | 240 | 6.7 FT. | 13.3 SQ. FT. | 480 | 2 |
| SCM243624-10 | 42145 | 240 | 10.0 FT. | 20.0 SQ. FT. | 720 | 3 |
| SCM243624-13 | 42146 | 240 | 13.3 FT. | 26.7 SQ. FT. | 960 | 4 |
| SCM243624-16 | 42147 | 240 | 16.7 FT. | 33.3 SQ. FT. | 1200 | 5 |
| SCM243624-20 | 42148 | 240 | 20.0 FT. | 40.0 SQ. FT. | 1440 | 6 |
| SCM243624-24 | 42149 | 240 | 24.2 FT. | 48.3 SQ. FT. | 1740 | 7.3 |
| SCM243624-27 | 42150 | 240 | 27.5 FT. | 55.0 SQ. FT. | 1980 | 8.3 |
| SCM243624-30 | 42151 | 240 | 30.8 FT. | 61.7 SQ. FT. | 2220 | 9.3 |
| SCM243624-34 | 42152 | 240 | 34.2 FT. | 68.3 SQ. FT. | 2460 | 10.3 |
| SCM243624-40 | 42153 | 240 | 40.8 FT. | 81.7 SQ. FT. | 2940 | 12.3 |
| SCM243624-47 | 42154 | 240 | 47.5 FT. | 95.0 SQ. FT. | 3420 | 14.3 |
| SCM243624-54 | 42155 | 240 | 54.2 FT. | 108.3 SQ. FT. | 3900 | 16.3 |
| SCM243624-61 | 42156 | 240 | 61.7 FT. | 123.3 SQ. FT. | 4440 | 18.5 |
| SCM243624-68 | 42157 | 240 | 68.3 FT. | 136.7 SQ. FT. | 4920 | 20.5 |
| SCM243624-79 | 42158 | 240 | 79.2 FT. | 158.3 SQ. FT. | 5700 | 23.8 |
| SCM243624-89 | 42159 | 240 | 89.2 FT. | 178.3 SQ. FT. | 6420 | 26.8 |
Ordering Information
| MODEL (30" WIDE) | UPC (093319) | VOLTS | MAT LENGTH | HEATED AREA (3" SPACING) | WATTS (48 W/FT2) | AMPS |
|---|---|---|---|---|---|---|
| SCM244830-4 | 42160 | 240 | 4.0 FT. | 10.0 SQ. FT. | 480 | 2 |
| SCM244830-6 | 42161 | 240 | 6.0 FT. | 15.0 SQ. FT. | 720 | 3 |
| SCM244830-8 | 42162 | 240 | 8.0 FT. | 20.0 SQ. FT. | 960 | 4 |
| SCM244830-10 | 42163 | 240 | 10.0 FT. | 25.0 SQ. FT. | 1200 | 5 |
| SCM244830-12 | 42164 | 240 | 12.0 FT. | 30.0 SQ. FT. | 1440 | 6 |
| SCM244830-14 | 42165 | 240 | 14.5 FT. | 36.3 SQ. FT. | 1740 | 7.3 |
| SCM244830-16 | 42166 | 240 | 16.5 FT. | 41.3 SQ. FT. | 1980 | 8.3 |
| SCM244830-18 | 42167 | 240 | 18.5 FT. | 46.3 SQ. FT. | 2220 | 9.3 |
| SCM244830-20 | 42168 | 240 | 20.5 FT. | 51.3 SQ. FT. | 2460 | 10.3 |
| SCM244830-24 | 42169 | 240 | 24.5 FT. | 61.3 SQ. FT. | 2940 | 12.3 |
| SCM244830-28 | 42170 | 240 | 28.5 FT. | 71.3 SQ. FT. | 3420 | 14.3 |
| SCM244830-32 | 42171 | 240 | 32.5 FT. | 81.3 SQ. FT. | 3900 | 16.3 |
| SCM244830-37 | 42172 | 240 | 37.0 FT. | 92.5 SQ. FT. | 4440 | 18.5 |
| SCM244830-41 | 42173 | 240 | 41.0 FT. | 102.5 SQ. FT. | 4920 | 20.5 |
| SCM244830-47 | 42174 | 240 | 47.5 FT. | 118.8 SQ. FT. | 5700 | 23.8 |
| SCM244830-53 | 42175 | 240 | 53.5 FT. | 133.8 SQ. FT. | 6420 | 26.8 |
Ordering Information
| MODEL (30" WIDE) | UPC (093319) | VOLTS | MAT LENGTH | HEATED AREA (4" SPACING) | WATTS (36 W/FT2) | AMPS |
|---|---|---|---|---|---|---|
| SCM243630-5 | 42176 | 240 | 5.3 FT. | 13.3 SQ. FT. | 480 | 2 |
| SCM243630-8 | 42177 | 240 | 8.0 FT. | 20.0 SQ. FT. | 720 | 3 |
| SCM243630-10 | 42178 | 240 | 10.7 FT. | 26.7 SQ. FT. | 960 | 4 |
| SCM243630-13 | 42179 | 240 | 13.3 FT. | 33.3 SQ. FT. | 1200 | 5 |
| SCM243630-16 | 42180 | 240 | 16.0 FT. | 40.0 SQ. FT. | 1440 | 6 |
| SCM243630-19 | 42181 | 240 | 19.3 FT. | 48.3 SQ. FT. | 1740 | 7.3 |
| SCM243630-22 | 42182 | 240 | 22.0 FT. | 55.0 SQ. FT. | 1980 | 8.3 |
| SCM243630-24 | 42183 | 240 | 24.7 FT. | 61.7 SQ. FT. | 2220 | 9.3 |
| SCM243630-27 | 42184 | 240 | 27.3 FT. | 68.3 SQ. FT. | 2460 | 10.3 |
| SCM243630-32 | 42185 | 240 | 32.7 FT. | 81.7 SQ. FT. | 2940 | 12.3 |
| SCM243630-38 | 42186 | 240 | 38.0 FT. | 95.0 SQ. FT. | 3420 | 14.3 |
| SCM243630-43 | 42187 | 240 | 43.3 FT. | 108.3 SQ. FT. | 3900 | 16.3 |
| SCM243630-49 | 42188 | 240 | 49.3 FT. | 123.3 SQ. FT. | 4440 | 18.5 |
| SCM243630-54 | 42189 | 240 | 54.7 FT. | 136.7 SQ. FT. | 4920 | 20.5 |
| SCM243630-69 | 42190 | 240 | 63.3 FT. | 158.3 SQ. FT. | 5700 | 23.8 |
| SCM243630-71 | 42191 | 240 | 71.3 FT. | 178.3 SQ. FT. | 6420 | 26.8 |
Ordering Information
| MODEL (36" WIDE) | UPC (093319) | VOLTS | MAT LENGTH | HEATED AREA (3" SPACING) | WATTS (48 W/FT2) | AMPS |
|---|---|---|---|---|---|---|
| SCM244836-3 | 42192 | 240 | 3.3 FT. | 10.0 SQ. FT. | 480 | 2 |
| SCM244836-5 | 42193 | 240 | 5.0 FT. | 15.0 SQ. FT. | 720 | 3 |
| SCM244836-6 | 42194 | 240 | 6.7 FT. | 20.0 SQ. FT. | 960 | 4 |
| SCM244836-8 | 42195 | 240 | 8.3 FT. | 25.0 SQ. FT. | 1200 | 5 |
| SCM244836-10 | 42196 | 240 | 10.0 FT. | 30.0 SQ. FT. | 1440 | 6 |
| SCM244836-12 | 42197 | 240 | 12.1 FT. | 36.3 SQ. FT. | 1740 | 7.3 |
| SCM244836-13 | 42198 | 240 | 13.8 FT. | 41.3 SQ. FT. | 1980 | 8.3 |
| SCM244836-15 | 42199 | 240 | 15.4 FT. | 46.3 SQ. FT. | 2220 | 9.3 |
| SCM244836-17 | 42200 | 240 | 17.1 FT. | 51.3 SQ. FT. | 2460 | 10.3 |
| SCM244836-20 | 42201 | 240 | 20.4 FT. | 61.3 SQ. FT. | 2940 | 12.3 |
| SCM244836-23 | 42202 | 240 | 23.8 FT. | 71.3 SQ. FT. | 3420 | 14.3 |
| SCM244836-27 | 42203 | 240 | 27.1 FT. | 81.3 SQ. FT. | 3900 | 16.3 |
| SCM244836-30 | 42204 | 240 | 30.8 FT. | 92.5 SQ. FT. | 4440 | 18.5 |
| SCM244836-34 | 42205 | 240 | 34.2 FT. | 102.5 SQ. FT. | 4920 | 20.5 |
| SCM244836-39 | 42206 | 240 | 39.6 FT. | 118.8 SQ. FT. | 5700 | 23.8 |
| SCM244836-44 | 42207 | 240 | 44.6 FT. | 133.8 SQ. FT. | 6420 | 26.8 |
Ordering Information
| MODEL (36" WIDE) | UPC (093319) | VOLTS | MAT LENGTH | HEATED AREA (4" SPACING) | WATTS (36 W/FT2) | AMPS |
|---|---|---|---|---|---|---|
| SCM243636-4 | 42208 | 240 | 4.4 FT. | 13.3 SQ. FT. | 480 | 2 |
| SCM243636-6 | 42209 | 240 | 6.7 FT. | 20.0 SQ. FT. | 720 | 3 |
| SCM243636-8 | 42210 | 240 | 8.9 FT. | 26.7 SQ. FT. | 960 | 4 |
| SCM243636-11 | 42211 | 240 | 11.1 FT. | 33.3 SQ. FT. | 1200 | 5 |
| SCM243636-13 | 42212 | 240 | 13.3 FT. | 40.0 SQ. FT. | 1440 | 6 |
| SCM243636-16 | 42213 | 240 | 16.1 FT. | 48.3 SQ. FT. | 1740 | 7.3 |
| SCM243636-18 | 42214 | 240 | 18.3 FT. | 55.0 SQ. FT. | 1980 | 8.3 |
| SCM243636-20 | 42215 | 240 | 20.6 FT. | 61.7 SQ. FT. | 2220 | 9.3 |
| SCM243636-22 | 42216 | 240 | 22.8 FT. | 68.3 SQ. FT. | 2460 | 10.3 |
| SCM243636-27 | 42217 | 240 | 27.2 FT. | 81.7 SQ. FT. | 2940 | 12.3 |
| SCM243636-31 | 42218 | 240 | 31.7 FT. | 95.0 SQ. FT. | 3420 | 14.3 |
| SCM243636-36 | 42219 | 240 | 36.1 FT. | 108.3 SQ. FT. | 3900 | 16.3 |
| SCM243636-41 | 42220 | 240 | 41.1 FT. | 123.3 SQ. FT. | 4440 | 18.5 |
| SCM243636-45 | 42221 | 240 | 45.6 FT. | 136.7 SQ. FT. | 4920 | 20.5 |
| SCM243636-52 | 42222 | 240 | 52.8 FT. | 158.3 SQ. FT. | 5700 | 23.8 |
| SCM243636-59 | 42223 | 240 | 59.4 FT. | 178.3 SQ. FT. | 6420 | 26.8 |
Ordering Information
| MODEL (24" WIDE) | UPC (093319) | VOLTS | MAT LENGTH | HEATED AREA (3" SPACING) | WATTS (48 W/FT2) | AMPS |
|---|---|---|---|---|---|---|
| SCM484824-10 | 42448 | 480 | 10.0 FT. | 20.0 SQ. FT. | 960 | 2.1 |
| SCM484824-25 | 42449 | 480 | 25.0 FT. | 50.0 SQ. FT. | 2400 | 5.1 |
| SCM484824-41 | 42450 | 480 | 41.3 FT. | 82.5 SQ. FT. | 3960 | 8.4 |
| SCM484824-61 | 42451 | 480 | 61.3 FT. | 122.5 SQ. FT. | 5880 | 12.5 |
| SCM484824-91 | 42452 | 480 | 91.9 FT. | 183.8 SQ. FT. | 8820 | 18.6 |
| SCM484824-102 | 42453 | 480 | 102.5 FT. | 205.0 SQ. FT. | 9840 | 20.9 |
| SCM484824-117 | 42454 | 480 | 117.5 FT. | 235.0 SQ. FT. | 11280 | 23.9 |
Ordering Information
| MODEL (24" WIDE) | UPC (093319) | VOLTS | MAT LENGTH | HEATED AREA (4" SPACING) | WATTS (36 W/FT2) | AMPS |
|---|---|---|---|---|---|---|
| SCM483624-13 | 42427 | 480 | 13.3 FT. | 26.7 SQ. FT. | 960 | 2.1 |
| SCM483624-33 | 42428 | 480 | 33.3 FT. | 66.7 SQ. FT. | 2400 | 5.1 |
| SCM483624-55 | 42429 | 480 | 55.0 FT. | 110.0 SQ. FT. | 3960 | 8.4 |
| SCM483624-81 | 42430 | 480 | 81.7 FT. | 163.3 SQ. FT. | 5880 | 12.5 |
| SCM483624-122 | 42431 | 480 | 122.5 FT. | 245.0 SQ. FT. | 8820 | 18.6 |
| SCM483624-136 | 42432 | 480 | 136.7 FT. | 273.3 SQ. FT. | 9840 | 20.9 |
| SCM483624-156 | 42433 | 480 | 156.7 FT. | 313.3 SQ. FT. | 11280 | 23.9 |
Ordering Information
| MODEL (30" WIDE) | UPC (093319) | VOLTS | MAT LENGTH | HEATED AREA (3" SPACING) | WATTS (48 W/FT2) | AMPS |
|---|---|---|---|---|---|---|
| SCM484830-82 | 42455 | 480 | 8.0 FT. | 20.0 SQ. FT. | 960 | 2.1 |
| SCM484830-20 | 42456 | 480 | 20.0 FT. | 50.0 SQ. FT. | 2400 | 5.1 |
| SCM484830-33 | 42457 | 480 | 33.0 FT. | 82.5 SQ. FT. | 3960 | 8.4 |
| SCM484830-49 | 42458 | 480 | 49.0 FT. | 122.5 SQ. FT. | 5880 | 12.5 |
| SCM484830-73 | 42459 | 480 | 73.0 FT. | 183.8 SQ. FT. | 8820 | 18.6 |
| SCM484830-82 | 42160 | 480 | 82.0 FT. | 205.0 SQ. FT. | 9840 | 20.9 |
| SCM484830-94 | 42461 | 480 | 94.0 FT. | 235.0 SQ. FT. | 11280 | 23.9 |
Ordering Information
| MODEL (30" WIDE) | UPC (093319) | VOLTS | MAT LENGTH | HEATED AREA (4" SPACING) | WATTS (36 W/FT2) | AMPS |
|---|---|---|---|---|---|---|
| SCM483630-10 | 42434 | 480 | 10.7 FT. | 26.7 SQ. FT. | 960 | 2.1 |
| SCM483630-26 | 42435 | 480 | 26.7 FT. | 66.7 SQ. FT. | 2400 | 5.1 |
| SCM483630-44 | 42436 | 480 | 44.0 FT. | 110.0 SQ. FT. | 3960 | 8.4 |
| SCM483630-65 | 42437 | 480 | 65.3 FT. | 163.3 SQ. FT. | 5880 | 12.5 |
| SCM483630-98 | 42438 | 480 | 98.0 FT. | 245.0 SQ. FT. | 8820 | 18.6 |
| SCM483630-109 | 42439 | 480 | 109.3 FT. | 273.3 SQ. FT. | 9840 | 20.9 |
| SCM483630-125 | 42440 | 480 | 125.3 FT. | 313.3 SQ. FT. | 11280 | 23.9 |
Ordering Information
| MODEL (36" WIDE) | UPC (093319) | VOLTS | MAT LENGTH | HEATED AREA (3" SPACING) | WATTS (48 W/FT2) | AMPS |
|---|---|---|---|---|---|---|
| SCM484836-6 | 42462 | 480 | 6.7 FT. | 20.0 SQ. FT. | 960 | 2.1 |
| SCM484836-16 | 42463 | 480 | 16.7 FT. | 50.0 SQ. FT. | 2400 | 5.1 |
| SCM484836-27 | 42464 | 480 | 27.5 FT. | 82.5 SQ. FT. | 3960 | 8.4 |
| SCM484836-40 | 42465 | 480 | 40.8 FT. | 122.5 SQ. FT. | 5880 | 12.5 |
| SCM484836-61 | 42466 | 480 | 61.3 FT. | 183.8 SQ. FT. | 8820 | 18.6 |
| SCM484836-68 | 42467 | 480 | 68.3 FT. | 205.0 SQ. FT. | 9840 | 20.9 |
| SCM484836-78 | 42468 | 480 | 78.3 FT. | 235.0 SQ. FT. | 11280 | 23.9 |
Ordering Information
| MODEL (36" WIDE) | UPC (093319) | VOLTS | MAT LENGTH | HEATED AREA (4" SPACING) | WATTS (36 W/FT2) | AMPS |
|---|---|---|---|---|---|---|
| SCM483636-8 | 42441 | 480 | 8.9 FT. | 26.7 SQ. FT. | 960 | 2.1 |
| SCM483636-22 | 42442 | 480 | 22.2 FT. | 66.7 SQ. FT. | 2400 | 5.1 |
| SCM483636-36 | 42443 | 480 | 36.7 FT. | 110.0 SQ. FT. | 3960 | 8.4 |
| SCM483636-54 | 42444 | 480 | 54.4 FT. | 163.3 SQ. FT. | 5880 | 12.5 |
| SCM483636-81 | 42445 | 480 | 81.7 FT. | 245.0 SQ. FT. | 8820 | 18.6 |
| SCM483636-91 | 42446 | 480 | 91.1 FT. | 273.3 SQ. FT. | 9840 | 20.9 |
| SCM483636-104 | 42447 | 480 | 104.4 FT. | 313.3 SQ. FT. | 11280 | 23.9 |
Ordering Information - Snow Melt Controls
| MODEL | UPC | DESCRIPTION | WEIGHT |
|---|---|---|---|
| SCS1 | 40502 | 25' Metal Cable Strapping for installation on existing concrete slab | |
| CIT-1 | 40504 | CIT-1 Aerial Snow Sensor | |
| SCIT-6E | 40505 | SIT-6E Pavement Sensor (requires 23832 Pavement Sensor Housing) | |
| 23832 Sensor Housing | 40506 | Pavement Sensor Housing (not pictured) | |
| SMNPLT | 40507 | Snow Melt Name Plate |
Ordering Information - Pyro Snow Melt System
| MODEL | UPC | Item | Description |
|---|---|---|---|
| PYROBOX3 | 42329 | Power Box 3 | 4 Zone Controller, 4-30A/2P Contactors, 1-Phase, 277V Max |
| PYROBOX3C | 42328 | Power Box 3C | 2 Zone Controller, 2-50A/3P Contactors, 3-Phase, 600V Max +1 Zone Aux Controller, 1-30A/2P Contactor, 1-Phase, 277V Max |
| PYROBOX5 | 42327 | Power Box 5 | 4 Zone Controller, 4-50A/3P Contactors, 3-Phase, 600V Max +1 Zone Aux Controller, 1-30A/2P Contactor, 1-Phase, 277V Max |
| PYROSENSE | 42323 | Snow sensor | Outdoor Snow Sensor |
| PYROULS | 42325 | Upper Limit Sensor | Upper Limit Temperature Sensor |
| PYROCON12 | 42322 | Main Controller | Controller and User Interface panel |
| PYROSB | 42326 | Mounting Bracket | Wall mounting adjustable rust free holding bar |
| PYROSENSE 2/3/4 | 42324 | Snow/Ice Sensor with Numerical Address | Option for Installations Where More Than One Snow Sensor Needed |
* Controls and thermostats should always be used with King heating systems.
Ordering Information - Pyro FPC System
| MODEL | UPC | Item | Description |
|---|---|---|---|
| FPC-02-120 | 19112 | Pyro FPC Freeze Protection Controller | Freeze Protection Controller 120V, 30A, w/GFEP |
| FPC-02-240 | 19113 | Pyro FPC Freeze Protection Controller | Freeze Protection Controller 240V, 30A, w/GFEP |
| FPC-02-120-MDB | 19114 | Pyro FPC Freeze Protection Controller | Freeze Protection Controller 120V, 30A, w/GFEP & MODBUS |
| FPC-02-240-MDB | 19115 | Pyro FPC Freeze Protection Controller | Freeze Protection Controller 240V, 30A, w/GFEP & MODBUS |
* Controls and thermostats should always be used with King heating systems.
Related Products
Model SC
- 208, 240, 480 volt
- 12 watts/per linear ft.
- Length: 35 to 535 ft.
SC Series Cable offers a custom in-concrete layout solution to snow and ice build-up, and can be installed to fit any individual application.
SnowFree™ System
- fully automated operation
- easy configuration
The ultimate “All in One” Snow Sensor & Controller for light commercial and residential use. A “Plug and Play” controlled for frost protection, ice and snow melt applications. For use with a high demand system on a regular or limited power supply source.
Model PYROBOX3
- Up to 30A & 300V Output
- Energy efficient algorithm
Automatic control and power distribution for de-icing and snow melting. For use with a high demand system on a regular or limited power supply source.
Model DS-8C
- 100-277V, 30 amp
- Includes precipitation sensor
Adjustable temperature setting range 34°F to 44°F. Rugged NEMA 3R enclosure with 1/2” electrical hub.
