SRP Series 240V Pre-Assembled Self-Regulating Pipe Trace Heating Cable is designed for a variety of pipe freeze protection applications. The cable is constructed so that it will not burn out or overheat when overlapped, and can be used on metal and plastic pipes. The cable is pre-terminated with a 30 inch cold lead and end-splice.
- Stops Pipe and Valve Freeze Down to -40°F
- Cable Will Not Burn Out Or Overheat When Overlapped
- Pre-terminated With 30 Inch Cold Lead and End-Splice
- Ready To Install
- Suitable For Use On Metal and Plastic Pipes
- 6 Watts/Linear Foot @ 40°F
- 16 Gauge Heating Cable Bus Wire
- Flouropolymer Insulation and Rugged PVC Jacked
- ETL Certified for USA and Canada
- 2-year limited warranty
Experience A Worry-Free Winter
Self-regulating heating cable, often called pipe trace cable, automatically adjusts heat output based on surface temperature. Ideal for freeze protection and low temperature process maintenance such as water pipe heating. Stops Pipe and Valve Freeze Down to -40°F.
Now That’s Smart!
Self-Regulating Design For Simple Installation and Operation
The cable is constructed so that it will not burn out or overheat when overlapped, and can be used on metal and plastic pipes. Self-Regulating design offering 6 Watts/Linear Foot @ 40°F.
Available Models
Ordering Information - 120V Models
| 120V MODEL | UPC | LENGTH | PIPE RATING* | DE-ICING RATING* | Purchase |
|---|---|---|---|---|---|
| SRP126-6 | 40400 | 6 FT. | 36 W | 48 W | Buy Now |
| SRP126-12 | 40402 | 12 FT. | 72 W | 96 W | Buy Now |
| SRP126-18 | 40404 | 18 FT. | 108 W | 144 W | Buy Now |
| SRP126-24 | 40406 | 24 FT. | 144 W | 192 W | Buy Now |
| SRP126-37 | 48711 | 37.5 FT. | 225 W | 300 W | Buy Now |
| SRP126-50 | 40408 | 50 FT. | 300 W | 400 W | Buy Now |
| SRP126-62 | 48712 | 62.5 FT. | 375 W | 500 W | Buy Now |
| SRP126-75 | 40410 | 75 FT. | 450 W | 600 W | Buy Now |
| SRP126-87 | 48713 | 87.5 FT. | 525 W | 700 W | Buy Now |
| SRP126-100 | 40412 | 100 FT. | 600 W | 800 W | Buy Now |
| SRP126-125 | 48714 | 125 FT. | 750 W | 1000 W | Buy Now |
| SRP126-150 | 48715 | 150 FT. | 900 W | 1200 W | Buy Now |
Ordering Information - 240V Models
| 240V MODEL | UPC | LENGTH | PIPE RATING* | DE-ICING RATING* | Purchase |
|---|---|---|---|---|---|
| SRP246-6 | 42373 | 6 FT. | 36 W | 48 W | Buy Now |
| SRP246-12 | 42374 | 12 FT. | 72 W | 96 W | Buy Now |
| SRP246-18 | 42375 | 18 FT. | 108 W | 144 W | Buy Now |
| SRP246-24 | 42376 | 24 FT. | 144 W | 192 W | Buy Now |
| SRP246-37 | 48716 | 37.5 FT. | 225 W | 300 W | Buy Now |
| SRP246-50 | 42377 | 50 FT. | 300 W | 400 W | Buy Now |
| SRP246-62 | 48717 | 62.5 FT. | 375 W | 500 W | Buy Now |
| SRP246-75 | 42378 | 75 FT. | 450 W | 600 W | Buy Now |
| SRP246-87 | 48718 | 87.5 FT. | 525 W | 700 W | Buy Now |
| SRP246-100 | 42379 | 100 FT. | 600 W | 800 W | Buy Now |
| SRP246-125 | 48719 | 125 FT. | 750 W | 1000 W | Buy Now |
| SRP246-150 | 48720 | 150 FT. | 900 W | 1200 W | Buy Now |
| SRP246-175 | 48721 | 175 FT. | 1050 W | 1400 W | Buy Now |
| SRP246-200 | 48722 | 200 FT. | 1200 W | 1600 W | Buy Now |
