MODEL WHF-HM

Home » Products » Residential Electric Heaters » Fan-Driven Heaters » MODEL WHF-HM

MODEL WHF-HM

high mount wall heater

The WHF-HM High Mount heater is designed for applications to be mounted 6’ above the floor. It is commonly used where wall space is limited. The high wall mounting allows you to use absolutely any wall in a room without affecting the furniture or decor placement. The WHF-HM provides extreme value by combining an open coil Ni-chrome wire element and squirrel cage blower.

  • Mounts 6 Feet Above the Floor
  • NiChrome Open Coil Element for Quick Heat Transfer
  • Whisper Quiet Squirrel Cage Blower
  • Dual Wattage Design
  • Patented Smart Limit Protection®
  • Proudly Made in the USA with U.S. & Global Materials
  • 3-Year Limited Warranty

Product Features

Warmth From Above. Out Of The Way Of Furniture

Mounts 6 Feet Above The Floor

WHF-HM is commonly used where wall space is limited. The high wall mounting allows you to use absolutely any wall in a room without affecting the furniture or decor placement.

Now That’s Smart!

Available Models

Ordering Information - Complete Stock Models

COMPLETE MODELUPCVOLTSWATTSAMPSSHIP WEIGHT lbs
WHF1210-HM-W20722120500 - 10004.2 - 8.38
WHF1212-HM-W20723120600 - 1200 5.0 - 10.08
WHF1215-HM-W20724120750 - 15006.3 - 12.58
WHF2010-HM-W20725208500 - 10002.4 - 4.88
WHF2015-HM-W20726208750 - 15003.6 - 7.28
WHF2020-HM-W207272081000 - 20004.8 - 9.68
WHF2410-HM-W20728240/208*500 - 10002.1 - 4.28
WHF2412-HM-W20729240/208*600 - 12002.5 - 5.08
WHF2415-HM-W20730240/208*750 - 15003.1 - 6.28
WHF2420-HM-W20731240/208*1000 - 20004.2 - 8.48
* Dual rated heaters will draw 13% less amps and 25% less wattage when operated at 208V.

Ordering Information - Factory Installed Options

ADD SUFFIXDESCRIPTIONSHIP WEIGHT lbs
-HHeatbox Interior Only (no can or grill)3.5
-IHeatbox Interior and Grill Only (no wall can)5.5
* Note: Not all configurations listed above are stock items (A+ or A stock code). Refer to price book for the Stock code. For non-stock items refer to the table below to order heater parts separately.
** Order A'la Carte **To build your own “Complete” with options (not noted above) select -H model of proper voltage, preferred wall can model and WHFG grill model of proper color.

Order A'la Carte Step 1 - Order Heatbox Interior

ADD SUFFIXDESCRIPTIONSHIP WEIGHT lbs
-HHeatbox Interior Only (no can or grill)3.5

Order A'la Carte Step 2 - Order Wall Can

MODELUPCDESCRIPTIONSHIP WEIGHT lbs
UIC12640Recess Wall Can3.5
UICF12540Recess Can with Flange (remodel)4
WHSC-W19204Surface Can - White - 13.5" H x 10.125" W x 4" D4
WHSC-A19205Surface Can - Almond - 13.5" H x 10.125" W x 4" D4

Order A'la Carte Step 3 - Order Grill

MODELUPCDESCRIPTIONSHIP WEIGHT lbs
WHFG-HM-A13509WHF ACCY GRILL FOR HIGH MOUNT HEATER ALMOND2
WHFG-HM-W12020WHF ACCY GRILL FOR HIGH MOUNT HEATER WHITE2
* Note: This is the quickest option when the factory installed heaters options are not in stock.

Ordering Information - Accessories

MODELUPCDESCRIPTIONSHIP WEIGHT lbsPurchase
TKIT-1BW20654Built-in Single Pole Single Throw Thermostat Kit, Bright White0.5Buy Now
TKIT-2BW20655Built-in Double Pole Single Throw Thermostat Kit, Bright White0.5Buy Now
TKIT-1A11058Built-in Single Pole Single Throw Thermostat Kit, Almond0.5Buy Now
TKIT-2A11059Built-in Double Pole Single Throw Thermostat Kit, Almond0.5Buy Now
TKIT-1-TP11056Built-in Tamper Proof Single Pole Single Throw Thermostat Kit0.4Buy Now
TKIT-2-TP11057Built-in Tamper Proof Double Pole Single Throw Thermostat Kit0.4Buy Now
DS1513824Disconnect Switch, Field Installed Kit, 10Amp 240V/15A 120V0.5Buy Now

Engineering Specs

Contractor shall supply and install WHF-HM Series in-wall mounted forced-air electric heaters manufactured by King Electrical Mfg. Company. Heaters shall be of the wattage and voltage as indicated on the plans.

Ratings: Heaters shall be available in wattages of 500 to 2,000 at 120, 208, or 240 Volts

Blower and Motor: A whisper quiet tangential blower, delivering 75 CFM, shall be driven by a shaded pole, permanently lubricated, C-frame type motor with impedance protection and sealed bearings. Motors shall be the same voltage as the heater. The motor and all wiring shall be totally isolated from the heating chamber for protection from heated air.

Thermal Overload: Heaters shall be equipped with King’s patented thermal overload Smart Limit Protection®, which disconnects elements and motor in the event normal operating temperatures are exceeded. If thermal overload trips due to abnormal operating temperatures, thermal overload shall remain open until manually reset by turning the heater off for 15 minutes. Automatic reset of thermal overloads, which allow the element to continue to cycle under abnormal conditions, will not be accepted.

Elements: Element assemblies shall be constructed of coiled nickel chromium alloy, corrosion resistant wire strung through a minimum of four rows of mica insulator. Element assemblies shall have factory provided connection to allow field modification to 50% wattage at time of installation.

Wall Can: The wall can shall be 20 gauge electrogalvanized steel and shall contain knockouts. The wall can shall be provided with a depth gauge, extending the full length of the wall can. The wall can shall be supplied with a factory installed groundwire. Minimum clearance 72” to floors, 6” to sidewalls, and 4” to the ceiling. Zero clearance to down flow.

Grill: The grill shall be a louvered, one-piece design with rounded edges on all four sides, with rounded corners to prevent snags from contact with other materials. The grill shall be epoxy powder- coated in the color specified by the manufacturer

Approvals: cULus (E41422)
